Kangaroo Ava 9301B - Prepare and Attach Panels Y2 and Y3

Assembly InstructionsAva
13
Step 1: Cabinet Shell
Y2
Y3
Y3
F2
8x30 Dowel Pin x8
d1
5
⁄
8
“ Cam Cover x2
c2
Insert d1 Dowel Pins into the
edges of Panels Y2 and Y3.
Set Panel Y2 aside for now.
Attach Panel Y3 to Panel F2, inserting
cam bolts into cam locks, tightening,
and applying c2 Cam Covers.
d1
