Kangaroo Ava 9301B - Attach Panel X to Main Structure

Assembly InstructionsAva
12
Step 1: Cabinet Shell
D
F1
F2
X
5
⁄
8
“ Cam Cover x6
c2
Attach Panel X to Panels D, F1 and F2, in-
serting cam bolts into cam locks, tightening,
and applying c2 Cam Covers.
