Kangaroo Ava 9301B - Slide Drawer Back Panel; Assemble Drawer Sides to Panel K5

Assembly InstructionsAva
22
Step 2: Drawers
K2
K3
K4
K6
K2
K3
K4
K6
K5
3.5x35 Screw x8
s2
X2
X2
Carefully slide Panel K6 into the grooves
on Panels K2, K3 and K4.
Repeat for second drawer.
Attach Panels K2 and K3 to Panel K5
as shown, using S2 Screws.
Repeat for second drawer.
s2
TIP: Be sure that K2 and K5 are flush against each other.
This will make installation of Panel K7 (drawer front) on
Page 23 easier.
