Kangaroo Ava 9301B - Assemble Drawer Sides K9, K10 to K11

Assembly InstructionsAva
25
K10
K9
K11
K13
K10
K9
K11
Step 2: Drawers
3.5x35 Screw x4
s2
Attach Panels K9 and K10 to Panel K11
as shown, using S2 Screws.
Carefully slide Panel K13 into the grooves
on Panels K9, K10 and K11.
s2
TIP: Be sure that K9 and K11 are flush against each oth-
er. This will make installation of Panel K8 (drawer front)
on Page 26 easier.
