Kangaroo Ava 9301B - Assemble Drawer Sides K9, K10 to K12; Attach Handle and Drawer Front K8

Assembly InstructionsAva
26
Step 2: Drawers
K9
K13
K11
K10
K12
K9
K8
3.5x35 Screw x4
s2
3.5x30 Screw x4
s1
4x20 Fix Bolt x2
b2
Handle x1
h
Attach Panels K9 and K10 to Panel
K12 as shown, using S2 Screws.
Attach h Handle with b2 Fix
Bolts.
Align Panel K8 with Pan-
el K9 and secure with s1
Screws as shown.
s2
s1
b2
h
TIP: Be sure that K12 and K9 are flush against each
other. This will make installation of Panel K8 (drawer
front) below easier.
