Kangaroo Ava 9301B - Attach Panel Assembly to Panel Z

Assembly InstructionsAva
8
Step 1: Cabinet Shell
O4
O1
O1
O1
Z
F1
F2
5
⁄
8
“ Cam Cover x8
c2
6x35 Cam Bolt x4
c1
8x30 Dowel Pin x12
d1
Attach Panel O1/O2/O3/O4 Assembly
to Panel Z as shown, inserting cam bolts
into cam locks. Tighten cam locks and
apply c2 Cam Covers.
Attach c1 Cam Bolts to Panels F1
and F2 as shown.
Insert d1 Dowel Pins into the edges
of Panels F1 and F2 as shown.
c1
d1
