Part 3: Top, Support Leaf and Quilt Panel
O1
O2
t1
s4
s1
h2
m
s2
h2
3.5x14 Screw x12
Hinge x4
s1
Magnet Catch
Plate x2
m
Alignment Pin x2
s4
14mm Wrench x1
Caster x2
r3
t2
Attach h2 Butt Hinges to Panels O1 and O2 using s1 Screws.
Attach m Magnet Catch Plates to underside of Panels O1 and O2 using s2 Screws.
Screw s4 Alignment Pins into the pre-drilled hole in the top of Panels O1 and O2.
Screw t1 Casters into the bottom of Panels O1 and O2. Tighten with r3 Wrench.
