Kangaroo K8805 - Page 21

Assembly InstructionsKangaroo
21
Part 4: Drawer Unit and Front Panel
L
K
Be sure that the silver
ball bearing
pieces are positioned all
the way to
the front of the rails.
TIP: Gently open and
close the drawers
a few times to engage the
Soft Close
mechanism.
Click Panel K into place.
Fully extend the cabinet
rails, align
drawer rails, and slide
drawers into caddy.
p1
A3
Magnet x1
m
p1
m
3.5x14 Screw x2
s1
Screw p1 Threaded Dowel Pins into Panel
A3 as shown above.
Using s1 Screws, attach m Magnet to
Panel A3 as illustrated.
s1
Threaded Dowel Pin x3
