Assembly InstructionsSydney XL
13
Step 2: Lift Installation
Lift rail
Plastic guides on Lift
Rail tabs
Lift rail
Cable
REMINDER: Our Customer Service Team is available for any assembly related questions. Please call 1-800-533-7347, ext. 1 to speak
with an Assembly Expert.
Guide Lift onto Lift Rails using plastic guides.
Insert ends of cable into rail tabs; make sure
the cable is hooked into the rail tabs on both
sides.
Cut the zip tie on the wooden block, but DO
NOT remove the block yet.
Lower the Lift to first lock position and
remove the wooden block. DO NOT
ADJUST LIFT POSITION until
the top is installed, or
you risk the Lift
coming out and
cables becoming
disengaged.
