Kangaroo Sydney - Prepare Leaf Panels with Hinges and Magnets

Assembly InstructionsSydney XL
15
Step 3: Top and Leaves
Butt Hinge x4
h3
3.5x14 Screw x24
s1
Magnet x0
Catch Plate
x2
m
Alignment Pin x2
s5
O3
04
04
O3
s1
h3
3x14 Screw x4
s2
m
s2
s5
s1
h3
Attach h3 Butt Hinges to Panels O3
and O4, using s1 Screws.
Flip panels over and attach
m Magnet Catch Plates using
s2 Screws.
Attach s5 Alignment Pins.
Attach Panels O3 and O4 to Panel Z
using s1 Screws.
O3
04
Z
s1
h2
