Kangaroo Sydney - Attach Hinges and Magnets to Leaf Panel A2

Assembly InstructionsSydney XL
16
Step 3: Top and Leaves
3.5x14 Screw x16
s1
Magnet x2
Catch Plate
x0
m
Butt Hinge x2
h3
A2
m
s1
s1
h3
h3
s1
A2
Attach h3 Butt Hinges and m Magnets to
Panel A2 with s1 Screws
Balance Panel A2 on Panels
O3 and O4. Using s1 Screws,
attach Hinges to Panel A from
underneath as shown.
O3
04
A2
A
