Kangaroo Sydney - Install Leaf Panel Hardware and Casters

Assembly InstructionsSydney XL
17
Step 3: Top and Leaves
Magnet x0
Catch Plate
x2
m
Butt Hinge x4
h3
3.5x14 Screw x12
s1
Alignment Pin x2
s5
Caster x2
t1
14mm Wrench x1
r3
3x14 Screw x4
s2
O2
O1
t1
s5
m
s2
t1
r3
Install h3 Butt Hinges
using s1 Screws.
Insert t1 Caster into
Caster Brackets and
tighten with Wrench.
Attach Magnet Catch
Plates m using s2
Screws.
Screw in
s5 Alignment
Pins.
s1
h3
