Kanto SYD - Front & Rear Panels; FRONT PANEL; REAR PANEL

OPT
Sub Out
L
R
RCA
RCA
USB Charge
5V/1000 mA
GND
ON OFF
POWER
AUX
Front & Rear Panels
4
Supporting your digital lifestyle
™
1
168 2 349 75
34
2
FRONT PANEL
1 1” Silk Dome Tweeter
2 4” Kevlar
®
Mid/Woofer Driver
3 Volume / Input Select / Standby / Wake-
up
4 Status LED
White - Power on / Playback Mode
Yellow - Standby (solid)
- Mute (ashing)
Blue - Discover Mode (ashing)
- Paired (solid)
REAR PANEL
1 RCA L/R Input
2 3.5 mm AUX Input
3 Optical Input
4 Subwoofer Output
5 Turntable Ground Post
6 RCA input Phono/Line switch
7 USB Charge Port (5 V 1.0A)
8 ON / OFF Switch
9 AC Input Connection
SYD’s volume knob functions as an input select knob as well.
Push the knob to select an input source - it cycles through the following inputs depending
on what input source was last used.
RCA AUX OPT BLUETOOTH
Push and hold the knob to enter standby or wake up from standby
