9
4. Select the laser beams you want to project as follows:
• Press H for the horizontal beam
• Press V1/V2 once for V1 vertical beam
• Press V1/V2 button twice for V1 and V2 vertical beams
5. To activate the Pulse mode push the Manual/Pulse
button once. The brightness of the beam appears to be
reduced when in Pulse mode.
To use in manual mode:
1. Push the Manual/Pulse button once to turn the device
ON. The manual mode indicator will blink.
2. Select the laser beams you want to project as follows:
• Press H for the horizontal beam
• Press V1/V2 once for V1 vertical beam
• Press V1/V2 button twice for V1 and V2 vertical beams
3. Set the required slope angle by tilting the unit.
4. To activate the Pulse mode push the Manual/Pulse
button one more time.
NOTE: Pressing the Manual Pulse button three times turns
the laser OFF.
