3. Remove the protective foil from the back
of the bracket (B3) and attach the on-board unit
to the cleaned dry area of the windscreen holding
it for at least 10 seconds (B4).
С: Use:
After following the installation instructions,
the on-board unit is now properly mounted and ready
for the following manipulations.
If necessary, the on-board unit can be taken
out of the bracket (C1) and put back before entering
the toll road.
Attention! When transported in another vehicle,
the on-board unit should be wrapped in protective
packaging, i.e. a metallized package (available at any
service point free of charge).
D: Control elements of the on-board unit:
1. Operating push-button.
2. LED indicators: «2, 3, 4» for axle setting.
3. LED indicator «X» for OBU status.
4. Acoustic signal (buzzer) sounds when passing
a tolling station only.
