Kärcher 297 M plus - Technical Data

18
9. TECHNICAL DATA
Power Connection
Voltage ............................................................ 240 V -AC
Current........................................................... 1~50 Hz
Connected/Load ............................................... 1.3 KW
Mains Fuse ........................................................ 13 AMP
Water Connection
Supply Temperature (Max)................................ 40 °C
Supply Rate (Min)............................................ 500 litres per Hour
Supply Pressure (Max) ...................................... 12 bar
Supply Hose Length ......................................... 7.5 metres
Diameter ........................................................... 1/2 inch
Performance Data
Pump Pressure (Max)...................................... 100 bar
Operating Pressure ........................................... 85 bar
Flow Rate ........................................................ 300 litres per hour
Detergent Intake ................................................ 20 litres per hour
Recoil Force of Hand Held Spray Gun
at Operating Pressure (Max) ............................. 10 N
Unit vibrations ................................................... 0.8 m/s²
Sound level
L
PA (EN 60704-1)............................................... 74 dB(A)
L
WA (2000/14/EEC)............................................ 84 dB(A)
Optimum Working Distance on High Pressure.. 30 cm
Dimensions
Length.............................................................. 240 mm
Width ............................................................... 300 mm
Height .............................................................. 555 mm
Weight ............................................................ 10,5 Kg
Circuit Diagram
C1 Capacitor
M1 Motor
Q1 Switch
T Temperature limiter
S1 Pressure switch
