3
1. Starting
Electrical Connection
• See technical data of connected values.
• Check whether the voltage shown on the rating
plate corresponds to that of the power source.
Note:
If you are using an extension cable, it
should always be completely unwound from the
cable drum and have a sufficient cross-sectional
area: 10 m = 1.5 mm², 30m = 2.5 mm²
Water Connection
• See technical data for connected values.
Note: Impurities in the intake water damage the
pump. To prevent this we expressly urge you to
use the Kärcher water filter (6).
• Screw the water filter onto the inlet water con-
nection of the machine.
• Screw the coupling (supplied with the machine)
onto the water filter.
• Connect a water supply hose to the machine using
a suitable hose connector to match the coupling on
the machine (hose and connector not supplied).
• Connect the high-pressure hose to the high-
pressure outlet.
Suction
Observe the following if you are drawing water
from an open container:
1. Attach a suction hose with filter (order no. 4.440-
570) directly to the water connection of the
machine.
2.Allow the pump to operate without the high-
pressure hose until water appears at the high-
pressure outlet without any more bubbles.
3.Then re-attach the high-pressure hose.
1 Connection lead
2 Appliance switch (ON/OFF)
3 High-pressure outlet
4 Carrying handle
5 Water connection
6 Water filter
7 Coupling
8 High-pressure hose
9 Spray gun with safety ratchet (A)
10 Spray lance with vario nozzle
11 Spray lance with dirt blaster
12 Detergent nozzle
13 Detergent container
Unpacking the appliance
• Please contact your dealer immediately if, on
unpacking the appliance, you discover damage
has been caused during transportation.
• Do not simply discard the packing materials
with the house-hold waste. Take the packing
materials to the appropriate collection areas for
recycling.
Fitting the accessories
• Screw the high-pressure hose onto the spray
gun.
• Connect the high-pressure hose to the high-
pressure outlet.
