Table of Contents
PAGE # DESCIPTION
2 Preface
2 Safety
3 Table of Contents
4 How the Machine Works
5 Technical specicaons
6-7 Product overview
8 Denions of the selector switch
9 Required tools
10-12 Vacuum motor removal procedure
13-14 Pump removal procedure
15-19 Brush motor removal procedure
20-22 Solenoid valve removal process
23-28 Steering sha removal
28-31 Tower removal procedure
32-33 Control board removal procedure
34-36 Miscellaneous repairs
37 Electrical troubleshoong,
explanaon of the technology
38-39 Electrical schemac
40 Skeletal view with test points
41 Main control board
42 12 volt power supply
43 Skeletal view of the soluon system
44 The machine is switched on but does not
power up.
PAGE # DESCIPTION
46 Machine operates, brush motor does not
run
47 Machine operates, the vac motor does not run
48 Machine operates, pump does not run
49 Machine operates, deep extracon spry does not
work
50 Machine operates, interim spray does not work
51-52 Error code troubleshoong
53-61 Product enhancements
