How the machine works:
The Armada is a 120 volt AC dual purpose carpet extractor intended for commercial use. This machine per-
forms Interim maintenance cleaning as well as deep restorave extracon. The soluon is applied during in-
terim cleaning and agitated into the carpet ber using a rotang cylindrical brush. The soluon is not recov-
ered but le to dwell on the carpet surface to be vacuumed up once the soluon has completely dried to the
touch (approximately 20 minutes). When using the appliance during deep extracon mode the soluon is
applied to the carpet agitated into the carpet ber using the cylindrical brush and recovered by the wet vac-
uum system. The soiled water is stored in the recovery tank to be disposed of when tank is at full capacity.
The appliance applies chemical at a reduced rate during interim cleaning using jet orice reducon.
The water is applied to the oor surface using a .001 Promax jet using a 100 psi pump with reduced pressure
to 50 psi. In deep extracon the water is dispensed through all three jets one .001 jet and two .003 jets at
100 psi. This is accomplished by the operators discreon using the specic funcons on the selector switch.
The appliance is equipped with the capability to us an oponal hand tool or spong wand that can
be aached using the male quick disconnect ng located on the brush head and vacuum hose located at
the top of the vacuum shoe.
The appliance is designed with an arculang brush head controlled by the operators handle. This
feature along with the capability of reversing the brush rotaon allows the appliance to clean in ght work
spaces. The handle is adjustable to the operators preference using the telescoping adjustment feature.
The appliance funcons are controlled by the operator using the rotang selector switch to select the
appropriate operang mode. The operaon of the brush and soluon spray is controlled by the soluon
switch and switch bar located on the steering console. The rotaon of the brush is controlled by the for-
ward/reverse switch located on the steering console.
