9. TECHNICAL DATA
Power Connection
Voltage...................................................... 230-240 V -AC
Current ........................................................... 1~50 Hz
Connected/Load.................................................1.9 KW
Mains Fuse ........................................................ 13 AMP
Water Connection
Supply Temperature (Max)................................ 40 °C
Supply Rate (Min) ............................................ 600 Litres per Hour
Supply Pressure (Max) ...................................... 12 bar
Supply Hose Length ......................................... 7.5 metres
Diameter ...................................... 1/2 inch
Performance Data
Pump Pressure (Max) .......................................130 bar
Operating Pressure ...........................................120 bar
Flow Rate ..........................................................400 litres per hour
Detergent Intake .................................................20 litres per hour
Recoil Force of Hand Held Spray Gun
at Operating Pressure (Max) ...............................15 N
Unit vibrations ................................................... 0.8 m/s²
Noise................................................................74,5 dB (A)
Optimum Working Distance on High Pressure .. 30 cm
Dimensions
Length ...............................................................395 mm
Width.................................................................315 mm
Height ...............................................................935 mm
Weight.................................................................12 Kg
Circuit Diagram
C1 Capacitor
M1 Motor
Q1 Switch
T Temperature limiter
S1 Pressure switch
