Kärcher HD 2.8/10 ST Ed B - User Manual

Kärcher HD 2.8/10 ST Ed B
32 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
9.800-086.0
OPERATOR’S MANUAL
MODEL # ORDER #
HD 2.8/10 ST Ed B / CB-301007D 1.575-300.0
HD 4.2/20 ST Ea B / CB-402007A 1.575-301.0
HD 4.2/20 ST Eb B / CB-402007B 1.575-302.0
HD 4.2/20 ST Ec B / CB-402007C 1.575-303.0
HD 4.2/20 ST Eg B / CB-402007G 1.575-304.0
HD 4.2/20 ST Eh B / CB-402007H 1.575-305.0
MODEL # ORDER #
HD 3.5/30 ST Ea B / CB-353007A
HD 3.5/30 ST Eb B / CB-353007B
HD 3.5/30 ST Ec B / CB-353007C
1.575-306.0
1.575-307.0
1.575-308.0
HD 3.5/30 ST Eg B / CB-353007G 1.575-309.0
HD 3.5/30 ST Eh B / CB-353007H 1.575-310.0
®
To locate your local Kärcher Shark Commercial Pressure Washer Dealer nearest you,
visit www.karchercommercial.com or www.karchershark.com

Questions and Answers

  • A
    Anthony JacksonAug 20, 2025
    Why is the Kärcher HD 2.8/10 ST Ed B pump running but pressure is low on installation?
    • K
      Kelly GarnerAug 20, 2025
      If the Kärcher Pressure Washer pump runs normally but the pressure is low upon installation, it could be due to several reasons. First, the pump might be sucking air, so check the water supply for any air intake. Alternatively, the valves might be sticking, requiring you to check, clean, or replace them. Another possibility is a faulty unloader valve seat, which should also be checked and replaced if necessary. Ensure the nozzle is correctly sized, replacing it if it is not. Lastly, worn piston packing can cause low pressure, so inspect and replace it if needed.
  • V
    Vanessa SnyderAug 22, 2025
    Why is the pressure fluctuating on my Kärcher HD 2.8/10 ST Ed B?
    • M
      Mary MillerAug 22, 2025
      Fluctuating pressure in your Kärcher Pressure Washer can be caused by several factors. Worn valves may be the culprit, requiring inspection and replacement. A blockage in a valve could also cause this issue; check and clean as necessary. The pump might be sucking in air, so examine the water supply connections. Worn piston packing can also lead to fluctuating pressure, so inspect and replace if needed. Finally, insufficient water supply could be the problem; check the filter and hose for any blockages or breakages.
  • A
    alexanderwilliamAug 25, 2025
    What to do if Kärcher Pressure Washer pressure is low after normal use?
    • L
      Logan JosephAug 25, 2025
      If your Kärcher Pressure Washer has low pressure after a period of normal use, several factors could be responsible. The nozzle may be worn, so check and replace it if necessary. The suction or delivery valves might be worn or blocked, requiring inspection, cleaning, or replacement. A worn unloader valve seat could also be the cause, needing a check and potential replacement. Additionally, the bypass valve within the unloader could be obstructed or leaking; remove and clean the bypass cartridge. Finally, worn piston packing can cause low pressure, so inspect and replace it if needed.
  • S
    Steve PerryAug 26, 2025
    How to fix a noisy Kärcher HD 2.8/10 ST Ed B pump?
    • Y
      Yolanda KleinAug 27, 2025
      A noisy Kärcher Pressure Washer pump can be attributed to several issues. Air in the suction line could be the cause, so check the water supply and connections on the suction line. A broken or weak suction or delivery valve spring may also lead to noise, requiring inspection and replacement. Foreign matter in the valves can cause noise, so check and clean if necessary. Worn bearings might also be the source of the noise; check and clean them. Lastly, excessive water temperature can make the pump noisy; reduce the temperature to below 140°F.
  • P
    Phillip FlemingAug 27, 2025
    What to do if the Kärcher HD 2.8/10 ST Ed B Pressure Washer motor will not run?
    • J
      Jennifer ChaseAug 27, 2025
      If the motor of your Kärcher Pressure Washer will not run, first check if the motor is overloaded. Push the overload button located on the motor (for single phase models) or the overload button on the magnetic start switch (for three phase models). Also, check the step down transformer fuses and voltage, replacing the fuses if necessary. Finally, if the coil of the magnetic starter is defective, replace it after testing the timer and unloader switch.
  • J
    Jessica DeckerAug 29, 2025
    Why is there water in the Kärcher Pressure Washer pump oil?
    • B
      Brianna GuerreroAug 30, 2025
      If you find water in the pump oil of your Kärcher Pressure Washer, it could be due to a worn oil seal, which would need checking and replacement. High humidity in the air can also cause this issue, in which case you should check and change the oil twice as often. Another potential cause is worn piston packing, requiring inspection and replacement.
  • M
    Mrs. Autumn Wheeler DVMAug 31, 2025
    Why is water dripping from under my Kärcher HD 2.8/10 ST Ed B Pressure Washer pump?
    • N
      nchandlerAug 31, 2025
      If water is dripping from under the pump of your Kärcher Pressure Washer, it could be due to worn piston packing or a worn O-Ring plunger retainer. Check and replace these parts as necessary.
  • K
    Karen SmithSep 2, 2025
    Why is there excessive vibration in the Kärcher HD 2.8/10 ST Ed B Pressure Washer high pressure hose?
    • S
      Susan BrownSep 2, 2025
      Excessive vibration in the high-pressure hose of your Kärcher Pressure Washer may be due to irregular functioning of the pump valves, which should be checked and replaced if necessary. Another cause could be an obstruction in the filter; clean the inlet filter to resolve this.
  • A
    Amy WoodsSep 4, 2025
    Why is oil dripping from my Kärcher HD 2.8/10 ST Ed B Pressure Washer pump?
    • J
      Jeremy LopezSep 4, 2025
      If oil is dripping from the pump of your Kärcher Pressure Washer, it is likely due to a worn oil seal. Check and replace the oil seal as necessary.
  • C
    Christopher PetersSep 6, 2025
    What to do if Kärcher HD 2.8/10 ST Ed B Pressure Washer will not turn on when switch is pushed?
    • D
      Darryl CarterSep 6, 2025
      If your Kärcher Pressure Washer will not turn on when the switch is pushed, the timer might be defective. Join wires 15 and 16 together on the timer. If the machine then works, replace the timer.

Kärcher HD 2.8/10 ST Ed B Specifications

General IconGeneral
Pressure100 bar
Operating pressure100 bar
Drive typeElectric
Max Pressure100 bar
Water Flow280 l/h
Voltage230 V
Frequency50 Hz
Pump typeAxial pump
