9.800-414.0 • Rev. 11/09
PRESSURE WASHER
OPERATOR’S MANUAL
5
EXPLODED VIEW PARTS LIST- SINGLE AXLE
ITEM
PART NO. DESCRIPTION QTY
1 9.800-006.0 Label, "Hot/Caliente" w/
Arrows Warning
1
2 9.800-008.0 Label, Danger Cool Engine 1
3 8.932-968.0 Label, Intended For
Outdoor Use
1
4 9.800-034.0 Label, Clear Lexan,
2-1/4" x 4-1/2"
1
5 9.800-036.0 Label, Warning, Pictoral, Small 1
6 9.803-842.0 Label, Instructions 1
7 9.800-046.0
8.901-145.0
8.900-281.0
Label, Belt Guard, Kärcher
Label, Belt Guard, BD
Label, Belt Guard, MP
1
1
1
8 8.9 3 2- 9 67.0 Label, Nozzle Identification 1
9 9.802-036.0 Nipple, 1/2" JIC, 3/8" Pipe 2
10 9.802-039.0 Elbow, 1/2" JIC, 3/8", 90° 1
11 9.802-048.0 Swivel, 1/2" JIC Fem, 3/8"
Male
1
12 9.802-064.0 Grommet, Rubber, Nozzle
Holder
5
13 9.802-066.0 Pad, Soft Rubber, 50 Duro 2
14 9.802-070.0 Grip, 1" Square, Handle 2
15 9.802-092.0 Belt Guard, CW 1
16 9.802-107.0 Fastener, Ratchet, Black Nylon 2
17 9.8 0 2-118.0 Elbow, 1/2" Street, Brass 1
18 9.802-129.0 Elbow, 1/2" JIC x 3/8", 90° 1
19 9.802-131.0 Elbow, 1/2" JIC x 1/2", 90° 1
20 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF
w/Strainer
1
21 9.802-151.0 Swivel, 1/2" JIC Fem, Push-On 4
22 9.802-163.0 Strainer, 1/2" PA, Inline Plastic 1
23 9.802-171.0 Nipple, 3/8" x 3/8" NPT ST
Male
1
24 8.707-254.0 Pump Protector, 3/8" PTP 1
25 9.802-241.0 Hose, 3/8" x 25", 2 Wire, Pres-
sure Loop
1
26 9.802-259.0 Hose, 1/2", Push-On 15"
27 9.802-271.0 Wheel & Tire Assy, 6" Steel
Rim w/Tube
2
28 9.802-295.0
Nozzle, SAQCMEG 0004, Red
(3200, 3500 PSI)
1
9.802-296.0 Nozzle, SAQCMEG 1504,
Yellow
(3200, 3500 PSI)
1
9. 8 0 2-297.0 Nozzle, SAQCMEG 2504,
Green
(3200, 3500 PSI)
1
9.802-298.0 Nozzle, SAQCMEG 4004,
White
(3200, 3500 PSI)
1
29 Engine, See Specifications
30 Pump, See Specifications
31 Unloader, See Specifications
ITEM
PART NO. DESCRIPTION QTY
32 Engine Pulley, See Specifica-
tions
33 Pump Pulley, See Specifica-
tions
34 Engine Bushing,
See Specifications
35
Pump Bushing, See Specifications
36 Belt, See Specifications
37 9.802-728.0 Bolt, 3/8" x 2" NCHH 6
38 9.802-723.0 Bolt, 3/8" x 1-1/2", NC HH 2
39 9.802-740.0 Bolt, 1/2" x 3-1/2", NC HH 1
40 9.802-744.0 Bolt, 10mm x 20mm, HH 4
41 9.802-753.0 Screw, 1/4" x 3/4" HH NC,
Whiz
3
42 9.197- 0 03.0 Nut, 3/8" ESNA, NC 4
43 9.802-782.0 Collar, 5/8" Bore Shaft 3010 4
44 9.802-809.0 Washer, 1/2" Flat 1
45 9.802-807.0 Washer, 3/8" Flat, SAE 8
46 9.802-807.0 Washer, 3/8" Flat, SAE 2
47 9. 80 2- 817.0 Washer, 3/8" x 1" 2
48 9.802-816.0 Washer, 7/16", Lock Split Ring 4
49 9.802-820.0 Washer, Nylon Spacer, 0.656"
x 1.25" x 0.65" Thick
2
50 9.802-870.0 Block, Unloader, 3/8" x 3/8",
1.25 Steel 1
51 9.803-103.0 Slider, Pump/Belt Guard
Mount, Red
1
52 9. 8 03 -110.0 Axle, 5/8" x 27.80 L 1
53 8.912-442.0
8.912- 441.0
Assy, Weld, CW Cage, Small
Black
Assy, Weld, CW Cage, Small
Red
1
1
54 9.197-0 0 3.0 Nut, 3/8" ESNA, NC 2
55 9.802-776.0 Nut, 5/16" ESNA 4
56 8.718-980.0 Washer, 5/16" Flat 4
57 8.706-984.0 Adapter, 1/2 x 1/2
(5000 PSI Models)
1
58 9.800-049.0 Label, Manufacturer's
Cleaning Solution
1
59 9.802-802.0 Washer, 1/4" Flat 3
60 9.802-225.0 Chemical Injector Assy,
3-5 GPM, .83
1
61
8.704-660.0
Label, Shark, Die-cut
(HD and BR Units)
1
62 8.917-015.0 Label, Regulation 4442.6 1
To Next Page
