English Operating Instructions HD 605
17
Technical Specifications
Mains connection
Voltage V 220–240
Type of current Hz 1~50
Connected load kW 2.2
Supply fuse (delayed-action) A 10
Water connection
Supply temperature (max.) °C60
Supply volume (min.) l/h 600
Supply hose – length m 7.5
Supply hose – minimum diameter inches ½
Suction height from an open container 20 °Cm1
Supply pressure (max.) bar 12
Performance data
Operating pressure bar 120
Flow rate l/h 500
Detergent intake l/h 0–25
Recoil force of the handgun N 21
Noise emission
Sound level (EN 60704-1) dB(A) 74
Guaranteed sound power level (2000/14/EC) dB(A) 90
Dimensions
Length mm 729
Width mm 312
Height mm 388
Weight without accessories kg 16
