8
English
8. Technical Specifications
HD 650
,(
1.150-105 1.150-106
Mains connection
CDN USA
'(2 97%
Voltage V 240 240
Type of current Hz 1~60 1~60
b b
Connected load HP 4.5 4.5
Supply fuse (delayed-action) A 16 16
Extension cable 10 m mm² 1.5 1.5
¯¯¯ ¯¯
Extension cable 30 m mm² 2.5 2.5
¯ ¯
Water connection
Supply temperature (max.) °C 60 60
Supply volume (min.) gpm 3.1 3.1
Supply hose – length m 7.5 7.5
Supply hose – minimum diameter inches 1/2 1/2
Suction height from an open container
20 °C
m 0.5 0.5
Supply pressure (max.) psi 140 140
Performance data
kpa psi
OTE TWM
Operating pressure 2000–14000 300–2000
Flow rate gpm 1.1–3.0 1.1–3.0
Detergent intake gpm 0–0.17 0–0.17
Recoil force of the handgun N 26 26
Sound level (DIN 45 635) dB(A) 78 78
Dimensions
Length mm 400 400
Width mm 340 340
Height mm 900 900
Weight without accessories kg 26.5 26.5
Reservoir capacity, detergent l 7 7
Oil quantity, pump l 0.4 0.4
Oil type, pump motor oil 15W40
