Manual Karcher 9.800-191.0
15
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEWS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 9.802-782.0 Collar, 5/8" Bore Shaft 4
2 8.758-460.0 Wheel 12 In. Rim Steel 4
3 9.802-810.0 Washer, 5/8", Flat, SAE 4
4 8.922-672.0 Axle Long 2
5 9.802-081.0 Tank, Fuel 6 Gallon Blank 1
6 9.802-089.0 Cap, Fuel Tank,
Plastic H60-AV 1
7 9.802-053.0 Bushing, Rubber, Nitrile 2
8 9.802-141.0 Hose Barb, 1/4" Barb x 3/8"
Barb, Double 1
9 9.802-177.0 Valve, 1/4" Shut-Off 1
10 9.802-138.0 Hose Barb,
1/4" Barb x 1/4" ML Pipe 1
11 6.390-126.0 Clamp, Hose, UNI .46 - .54 4
12 9.802-254.0 Hose, 1/4" Push-On,
Fuel Line 8"
13 9.802-254.0 Hose, 1/4" Push-On,
Fuel Line 7"
14 9.800-018.0 Label, Tipover Hazard 1
15 8.757-203.0 SWIVEL, 1/2" M-NPTF
x 3/4" GHF 1
16 9.198-014.0 Washer 21/64 X 1" 4
17 8.757-616.0 Elbow steel 1/2 JIC (M)
x 3/8 BSPP (M) (352007A) 1
8.757-935.0 Adapter steel 1/2 JIC
x 3/8 NPTF (F) 90° 1
18 9.804-025.0 Pump Protector, 1/4", 145° 1
20 9.802-720.0 Bolt, 3/8" x 1", NC HH 4
21 9.802-807.0 Washer, 3/8", SAE, Flat Zinc 4
22 8.929-254.0 Pump KARCHER
KFP2030S, 2.1 @3000
1725RPM (511.0, 512.0) 1
8.929-259.0 Pump KARCHER KFP3530F,
3.5 @3000 3450RPM (513.0) 1
23 9.802-458.0 Switch, Pressure,
N/O, 1/4" NPT SS 1
24 9.804-516.0 Motor, 1.5 HP 120V
1725 RPM (511.0) 1
8.754-709.0 Motor, 2HP 1PH 115V
1750 RPM, 56C ODP 1
9.802-341.0 Motor, 5HP 1PH 230V
3450 RPM (513.0) 1
25 9.802-804.0 Washer, 5/16" Flat, SAE 8
26 9.802-776.0 Nut, 5/16" ESNA, NC 8
27 9.802-427.0 Cord, Service, SOWA, 3 ft.
12/3 (512.0)
9.802-436.0 Cord, Service, SEO, 2.67 ft.
(10/3 511.0, 513.0)
28 8.752-969.0 Strain Relief, Lt, Str, 1/2 NPT
0.39-0.75ID (511.0, 512.0) 1
9.802-518.0 Strain Relief,
STRT LQ TITE (513.0) 1
ITEM PART NO. DESCRIPTION QTY
29 9.802-526.0 Locknut, 3/4" 8465 (513.0) 1
30 8.754-696.0 Unloader, VBT Banjo
1/2M 3/8M, 3000PSI 1
9.175-018.0 UU1 3500PSI,Universal
Unloader (352007A) 1
31 9.800-049.0 Label, Manufacturer's
Cleaning Solution 1
33 8.918-425.0 Hose, 3/8" x 29", 2 Wire,
Pressure Loop 1
34 9.800-002.0 Label, Use Only Kerosene 1
35 8.757-240.0 Manifold coil outlet
discharge w/slnt 1
36 8.902-433.0 Valve Safety, Relief 1
37 9.196-012.0 Plug 10-24UNF x 1/4 1
38 8.711-785.0 Hose, 3/8" Push-On 2.75 ft.
39 8.707-152.0 Nipple, 3/8", Male, Ssteel 1
41 9.800-021.0 Label, Hot Water Outlet 1
42 9.800-110.0 Label, Kärcher Logo 2
43 8.911-802.0 Coil wrap SS 16" 1
8.911-800.0 Coil wrap SS 16" 1
(For models HDS 3.5/20 EA)
44 8.757-655.0 Adapter Steel 1/2" 1
JIC x 3/8"
8.757-508.0 Adapter steel 1/2" JIC 1
x 1/2" (For models HDS 3.5/20)
45 8.706-241.0 Plug 3/8" square head 1
8.757-625.0 Plug 1/2" square head 1
(For models HDS 3.5/20)
46 8.925-219.0 Spare coil 16" MTY 1
8.925-218.0 Spare coil 16" MTY Large 1
47 9.800-041.0 Label, Warning, Text 1
48 9.800-006.0 Label, Hot/Caliete 1
w/Arrows Warning
49 8.719-913.0 Top Hat, Coil 1
50 9.802-904.0 Insulation, Tank Head, 1
16" OD x 8" ID
51 9.802-825.0 Clip, Retaining U-Type 4
52 8.757-944.0 Tee steel 3/8" 1
8.757-615.0 Tee steel 1/2" 1
(For models HDS 3.5/20EA)
53 8.757-198.0 Elbow, 1/4" Street, Brass 1
54 9.803-108.0 Retainer Ring, Insulation 1
55 9.802-900.0 Insulation, Tank Bottom,
1" Blanket 1
56 9.803-120.0 Assembly, Frame, Black 1
57 8.705-974.0 Nipple steel hex 3/8" 1
8.757-338.0 Nipple 1/2" Hex Steel 1
(For models HDS 3.5/20 EA)
58 8.750-094.0 Thermostat, 150C/302F 1
59 8.706-241.0 Plug, 3/8, SQ head 1
60 8.757-551.0 Elbow Street Steel 3/8" 45° 1
61 9.802-753.0 Screw, 1/4-20 x 3/4" Loc 2
