Kärcher K 090 - Technical Data

20
9. TECHNICAL DATA
Power Connection
Voltage .................................................................. 220-240 V-AC
Current .................................................................. 1~50/60 Hz
Connected/Load ............................................................ 1.4 KW
Mains Fuse..................................................................... 13 AMP
Water Connection
Supply Temperature (Max) ............................................ 40 °C
Supply Rate (Min) ............................................................ 8 litres per minute
Supply Pressure (Max) .............................. (12 bar) .... 1,2 MPa
Supply Hose Length ...................................................... 7.5 metres
Diameter................................................... 1/2 inch
Performance Data
Pump Pressure (Max at bypass) .............. (100 bar) ..... 10 MPa
Operating Pressure .................................... (80 bar) ....... 8 MPa
Flow Rate ................................................. (330 l/h) ...... 5,5 litres per minute
Detergent Intake ............................................................ 0,3 litres per minute
Recoil Force of Spray Gun at Max. Pressure................. 10 N
Optimum Working Distance on High Pressure ............... 30 cm
Hand-transmitted vibration (ISO 5349) ......................... 0,8 m/s²
Sound pressure level L
PA
(EN 60704-1) .......................... 77 dB(A)
Sound power level L
WA
(2000/14/EC) .............................. 92 dB(A)
Dimensions
Length .......................................................................... 365 mm
Width ............................................................................ 145 mm
Height ........................................................................... 250 mm
Weight .............................................................................. 5 Kg
Circuit Diagram
M1 Motor
Q1 Appliance switch
S1 Pressure-operated switch
Z 1 Suppressor
