Kärcher K 1 - Operating Modes; Charging the Battery; Battery Operation; Operation

English 17
 Screw the suction hose into the water
connection of the appliance and insert it
into the water source (e.g. rainwater
drum).
 Separate the high pressure hose from
the high pressure connection of the ap-
pliance.
 Switch the appliance on (I/ON) for a
max. of 2 minutes and wait until the wa-
ter exits the high-pressure connection
without bubbles.
 Turn off the appliance "0/OFF".
 Turn on the appliance “I/ON”.
The displays for battery operation and
mains operation are subjected to a brief
test routine and will illuminate consecu-
tively.
 The display for battery operation illumi-
nates continuously and shows the bat-
tery status.
The appliance is now ready for opera-
tion.
– Battery empty: Motor will be switched
off, the three red LEDs will blink and
thhen shine ca. 60 seconds - then the
appliance will shut off on its own.
– Engine or battery pack is too hot: the
appliance will shut off on its own.
 Connect charging station with power
cord and plug into the mains socket.
 Insert the battery pack into the charger.
ATTENTION
Dry running of more than 2 minutes leads to
damage of the high-pressure pump. If the
appliance does not build up pressure within
2 minutes, switch the appliance off and pro-
ceed in accordance with the instructions in
Chapter "Troubleshooting".
 Pressing the „ON-/OFF“-switch starts
the appliance in maximum mode.
 Pressing the „ON-/OFF“-switch again
switches to the ECO-mode.
 Pressing the „ON-/OFF“-switch again
switches the appliance off.
몇 CAUTION
Keep a distance of at least 30 cm when us-
ing the jet for cleaning painted surfaces to
avoid damage.
Illustration
 Push the spray lance into the trigger gun
and fasten it by turning it through 90°.
 Turn on the appliance “I/ON”.
 Unlock the lever on the trigger gun.
 Pull on the lever of the trigger gun; the
device will switch on.
Note: Release the lever of the trigger
gun; the device will switch off again.
High pressure remains in the system.
Drawing in water from open reservoirs
Battery operation
Display battery oper-
ation
Charging status
of the battery
pack
green LED red LED
3 0 70% - 100%
2 0 40% - 70%
1 0 20% - 40%
0 3 blinking 10% - 20%
0 3 1% - 10%
Charging the battery
LED 1 LED 2
No battery pack in the
charger
OFF OFF
Low voltage protection OFF Blinking
Charging process Blinking OFF
Charging process com-
pleted
ON OFF
Temperature too high OFF ON
Short-circuit OFF ON
Operation
Operating modes
High pressure operation
