English 9
Subject to technical modifications!
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
D - 71364 Winnenden
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Power connection
Voltage 220-240
1~50/60
V
Hz
Connected load 1,4 kW
Mains fuse (slow-blow) 13 A
Protective class II
Protection class IP X5
Water connection
Max. feed temperature 40 °C
Min. feed volume 8 I/min
Feed pressure 0,2-1,2 MPa
Performance data
Working pressure 8 MPa
Max. permissible pressure 10 MPa
Water flow rate 5,5 I/min
Detergent flow rate 0,4 I/min
Recoil force of trigger gun 12 N
Hand-arm vibration
(ISO 5349)
0,8 m/s
2
Sound pressure level
L
pA
(EN60704-1)
75 dB(A)
Sound power level
L
WA
(2000/14/EG)
89 dB(A)
Dimensions
Length 374 mm
Width 152 mm
Height 256 mm
Weight 4,2 kg
CE declaration
Product: High-pressure cleaner
Type: 1.601-xxx
Relevant EU Directives
2006/95/EC (to 28.12.2009)
2006/42/EC (from 29.12.2009)
2004/108/EC
2000/14/EC
Applied harmonized standards
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006
EN 61000–3–3: 2008
EN 62233: 2008
Applied conformity evaluation method
Appendix V
Sound power level dB(A)
Measured: 87
Guaranteed: 89
