Kärcher K 2 Full Control Original Operating Instructions

– 7
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.
The signatories act on behalf of and with the authority of
the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212
Accessories and Spare Parts
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IP X5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 l/min
Performance data
Working pressure 7,4 MPa
Max. permissible pressure 11 MPa
Water flow rate 5,5 l/min
Max. flow rate 6,0 l/min
Recoil force of trigger gun 11 N
Dimensions and weights
Length 246 mm
Width 280 mm
Height 586 mm
Weight, ready to operate with acces-
sories
5,1 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
<2,5
0,3
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
75
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertainty
K
WA
90 dB(A)
Subject to technical changes.
Warranty
EU Declaration of Conformity
Product: High pressure cleaner
Type: 1.673-xxx
Relevant EU Directives
2000/14/EC
2014/30/EU
2006/42/EC (+2009/127/EC)
2011/65/EU
Applied harmonized standards
EN 50581
EN 55014–1: 2006+A1: 2009+A2: 2011
EN 55014–2: 2015
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN 62233: 2008
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 88
Guaranteed: 90
Winnenden, 2018/08/01
Chairman of the Board of Management
Director Regulatory Affairs & Certification
11EN

Kärcher K 2 Full Control Specifications

General

Form factor	Upright
Hose length	4 m
Power source	Electric
Water filter	Yes
Product color	Black, Yellow
Pressure range	High-pressure
Protection class	II
International Protection (IP) code	IPX5
Uncertainty K	0.3 m/s²
Maximum flow rate	6 l/h
Minimum flow rate	5.5 l/h
Sound power level	88 dB
Vibration emission	2.5 m/s²
Sound pressure level	75 dB
Working pressure (max)	20 bar
Maximum area performance	20 m²/h
Sound power level uncertainty	90 dB
Maximum input water temperature	40 °C
Fuse	10 A
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	1400 W
Wash brush	-

Weight and Dimensions

Depth	246 mm
Width	280 mm
Height	586 mm
Weight	4300 g
