Kärcher K 2 Universal Edition Quick Start Guide

10 English
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IPX5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 l/min
Performance data
Working pressure 8 MPa
Max. permissible pressure 12
1750
MPa
psi
Water flow rate 5,5 l/min
Max. flow rate 6,0 l/min
Detergent flow rate 0,3 l/min
Recoil force of trigger gun 12 N
Dimensions and weights
Length 280 mm
Width 182 mm
Height 390 mm
Typical operating weight 4,5 kg
Subject to technical changes.

Kärcher K 2 Universal Edition Specifications

General

Pressure	110 bar
Flow Rate	360 L/h
Hose Length	3 m
Area Performance	20 m²/h
Water Feed Temperature	max. 40 °C
Voltage	220-240 V
Detergent Tank	No
Motor Power	1.4 kW
Frequency	50 Hz
Weight	3.8 kg (without accessories)
