Kärcher K 200 plus - Technical Data

18
9. TECHNICAL DATA
Power Connection
Voltage ...................................................... 230-240 V -AC
Current ........................................................... 1~50 Hz
Connected/Load................................................. 1.2 KW
Mains Fuse .........................................................13 AMP
Water Connection
Supply Temperature (Max) .................................40 °C
Supply Rate (Min) .............................................500 Litres per Hour
Supply Pressure (Max)........................................12 bar
Supply Hose Length ...........................................7.5 metres
Diameter ............................................................1/2 inch
Performance Data
Pump Pressure (Max) .......................................100 bar
Operating Pressure .............................................85 bar
Equivalent Washing Efficiency (EWE)
with dirt blaster .................................................. 150
Flow Rate .......................................................... 300 litres per hour
Detergent Intake .................................................20 litres per hour
Recoil Force of Hand Held Spray Gun
at Operating Pressure (Max) ...............................10 N
Unit vibrations ....................................................0.8 m/s²
Noise level L
PA
(EN 60704-1) ..............................74 dB (A)
Noise level L
WA
(EN 4871) ..................................87 dB(A)
Optimum Working Distance on High Pressure ....30 cm
Dimensions
Length ...............................................................375 mm
Width ................................................................. 204 mm
Height ............................................................... 294 mm
Weight .................................................................10 Kg
Circuit Diagram
C1 Capacitor
M1 Motor
Q1 Switch
T Temperature limiter
S1 Pressure switch
