1 800-537-4129 page 3
Step1 Connect the high pressure hose to
the unit’s high pressure outlet.
Step4 Insert the spray wand of your
choice into the wand extension. Press in
against the spring tension and twist into
the locked position.
Step2 Connect garden hose to unit’s
water inlet.
ASSEMBLY INSTRUCTIONS
Water Supply
(Cold Water Only)
• Water hose must be at least 3/4 inch in
diameter.
• Flow rate of water supply must not fall
below 2.5 GPM (gallons per minute).
• Flow rate can be determined by running
the water for one minute into an empty
5-gallon container.
IMPORTANT PRECAUTIONS –
continued
• The water supply temperature must not
exceed 104°F/40°C.
• Never use the pressure washer to draw in
water contaminated with solvents, e.g. paint
thinners, gasoline, oil, etc.
• Always prevent debris from being drawn into
the unit by using a clean water source.
Step3 Slide the spray
wand extension into the
gun. Turn the wand collar
onto the gun threads until
tight.
