English 3
Français 20
Español 40
59630170 (12/10)
K 3.48 M
HIGH PRESSURE WASHER - OPERATOR MANUAL
NETTOYEUR HAUTE PRESSION - MANUEL D'UTILISATION
MANUAL DE USUARIO DEL LIMPIADOR DE ALTA PRESIÓN

Table of Contents

Questions and Answers

  • D
    Dawn HendersonAug 20, 2025
    What to do if the output pressure varies on my Kärcher Pressure Washer?
    • J
      Jose WattsAug 20, 2025
      If the output pressure of your Kärcher Pressure Washer varies, ensure that the water is turned on full force and inspect the garden hose for kinks, leaks, or blockages. Check for air leaks in hoses and fittings; if present, turn off the machine and purge the pump by squeezing the trigger gun until water flows steadily through the nozzle. Clean the water inlet filter by removing and rinsing it in warm water. Clear any obstructions from the discharge nozzle using a fine needle. If the gun, hose, or spray wand is calcified, run distilled vinegar through the detergent suction tube.
  • L
    Lisa WoodAug 22, 2025
    How to fix Kärcher K 3.48 M Pressure Washer motor that will not start?
    • T
      tiffanymedinaAug 22, 2025
      If your Kärcher Pressure Washer motor won't start, there are several potential causes: * The On/Off switch might be in the “OFF” (0) position. If so, turn the switch to the “ON” (I) position. * The power cord might not be plugged in. Ensure the power cord is properly plugged in. * The electrical outlet may not supply adequate power. Try a different outlet. * The GFCI plug might be tripped. Press the “RESET” button on the GFCI plug. * The circuit breaker may be tripped. Switch off the pressure washer. The reset will occur automatically once the unit's temperature drops.
  • G
    garrett51Aug 25, 2025
    Why does the output pressure vary high and low on my Kärcher K 3.48 M Pressure Washer?
    • C
      courtneyguzmanAug 25, 2025
      If your Kärcher Pressure Washer's output pressure varies, it could be due to several reasons: * Insufficient inlet water supply. Ensure the water is turned on full force and check the garden hose for any kinks, leaks, or blockages. * The pump might be sucking air. Check that all hoses and fittings are airtight. Turn off the machine and purge the pump by squeezing the trigger gun until a steady flow of water emerges through the nozzle. * A clogged water inlet filter. Remove the filter and rinse it out in warm water. * An obstructed discharge nozzle. Blow out or remove any debris with a fine needle. * Calcification in the gun, hose, or spray wand. Run distilled vinegar through the detergent suction tube.
  • S
    Stephanie RodriguezAug 26, 2025
    Why doesn't my Kärcher Pressure Washer reach high pressure?
    • J
      Jimmy MclaughlinAug 26, 2025
      If your Kärcher Pressure Washer isn't reaching high pressure, consider the following: * The diameter of your garden hose might be too small. Replace it with a 5/8 inch or larger garden hose. * The water supply could be restricted. Check the garden hose for kinks, leaks, and blockages. * There might not be enough inlet water supply. Open the water source fully. * The water inlet filter might be clogged. Remove the filter and rinse it in warm water. * The spray wand might be on the low-pressure position. Turn the spray wand to the high-pressure position.
  • N
    Nancy GayAug 27, 2025
    What to do if my Kärcher K 3.48 M is not dispensing detergent?
    • J
      John WillisAug 28, 2025
      If your Kärcher Pressure Washer isn't dispensing detergent, here are some things to check: * Ensure the detergent suction tube is properly connected to the machine. * If the detergent is too thick, dilute it. For best results, use Kärcher® detergent. * Check if the filter on the detergent suction tube is clogged. Run warm water through the filter to remove any debris. * Inspect the detergent suction tube for damage or clogs. Remove any obstructions or replace the tube if necessary. * Make sure the spray wand is not in the high-pressure position; turn the spray wand tip to the low-pressure position. * The discharge nozzle may be obstructed. Blow out or remove debris with a fine needle.
  • D
    driceAug 29, 2025
    Why is the garden hose connection leaking on my Kärcher Pressure Washer?
    • B
      Betty WattsAug 30, 2025
      If your garden hose connection is leaking on your Kärcher Pressure Washer, try these solutions: * Tighten any loose fittings. * If there's a missing or worn rubber washer, insert a new one.
  • H
    humphreylaurenAug 31, 2025
    Why is the pump on my Kärcher K 3.48 M so noisy?
    • P
      Patrick GarciaAug 31, 2025
      If your Kärcher Pressure Washer's pump is noisy, it might be sucking in air. Check that all hoses and fittings are airtight. Turn off the machine and purge the pump by squeezing the trigger gun until a steady flow of water emerges through the nozzle.
  • A
    ariana63Sep 2, 2025
    Why is my Kärcher K 3.48 M spray wand leaking?
    • J
      Janice BennettSep 2, 2025
      If the spray wand on your Kärcher Pressure Washer is leaking: * Ensure the spray wand is properly attached. Insert the spray wand into the trigger gun, carefully press it in against the spring tension, and twist it into the locked position. * If there is a broken o-ring or plastic insert, call Customer Support.
  • C
    Christina MorrisonSep 4, 2025
    Why is water leaking from the pump of my Kärcher K 3.48 M Pressure Washer?
    • D
      Daniel AlvarezSep 4, 2025
      If water leaks from the pump of your Kärcher Pressure Washer (up to 10 drops per minute is permissible): * Check that all fittings are tight. * If the water seals are damaged or worn, call Customer Support.
  • M
    Michael SmithSep 6, 2025
    What should I do if I see an oil drip from my Kärcher K 3.48 M?
    • D
      Dr. Joseph LeonSep 6, 2025
      If you observe an oil drip from your Kärcher Pressure Washer and suspect that the oil seals are damaged or worn, call Customer Support.

Summary

Safety Alert Symbols

DANGER

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Indicates a potentially hazardous situation which, if not avoided, could result in death or injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or in property damage incidents.

Owner;User Responsibility

Specifications

Model Overview

Main Unit Components

Identifies key parts like water inlet, outlet, controls, and storage features.

Spray Gun and Accessories

Details the trigger gun, safety lock, hose, and spray wands.

Important Safety Instructions

Injection and Explosion Hazards

Warnings about direct discharge streams and flammable liquids.

Handling and Electrical Safety

Advice on gun handling, electrocution risks, and electrical apparatus.

Detergent Use and Warnings

Guidance on recommended detergents and prohibited chemicals.

Grounding and GFCI Protection

Grounding Instructions

Ensuring proper grounding for electrical safety.

GFCI Protection

Explanation of the ground-fault circuit-interrupter safety feature.

Water Supply

Water Connection Regulations

Adherence to local water company regulations for connection.

Water Supply Requirements

Details on hose diameter, flow rate, and temperature.

Water Contamination Warning

Avoidance of using contaminated water for operation.

Assembly Instructions

Required Tools and Initial Assembly

Lists necessary tools and steps for mounting loose parts.

Connecting and Disconnecting Hose

Procedure for attaching and removing the high pressure hose.

Operating Instructions

Connecting Hoses and Wands

Steps for connecting the high pressure hose, spray wand, and water inlet.

Connecting Water Supply

Procedure to connect the garden hose to the unit and water source.

GFCI and System Purge

Steps for plugging in, testing GFCI, and purging air from the system.

Starting the Unit

How to unlock the trigger gun and start the motor.

Using Accessories and Detergents

Accessory Usage

Guidance on using the Vario Power Spray Wand and Dirtblaster nozzle.

Working with Detergents

Steps for applying detergent and filling the detergent tank.

Detergent Application and Cleaning

Detergent Application and Rinsing

Steps for applying detergent and rinsing surfaces.

Detergent System Flush

Instructions for flushing remaining detergents from the injection system.

Detergent Recommendations and Warnings

Information on recommended and prohibited detergents.

Taking a Break

Securing the Trigger Gun

Procedure to release the trigger and engage the safety lock.

Powering Off the Unit

Steps to turn the pressure washer to the OFF position.

Shutting Down and Clean-Up

Powering Down and Disconnecting

Steps to turn off the unit, unplug, and disconnect water sources.

Releasing Pressure and Disconnecting Hoses

Procedure to release residual pressure and detach hoses.

Winterizing and Long-Term Storage

Storage Preparation

Disconnecting water, draining the pump, and proper storage environment.

Pump Protector Use

Recommendation for using a pump protector for cold weather storage.

Care and Maintenance Instructions

Cleaning the Water Inlet Filter

Step-by-step guide to cleaning the water inlet filter.

Maintenance Summary

Note indicating the unit is maintenance-free.

Cleaning Tips

General Cleaning Precautions

Advice on testing surfaces and handling painted surfaces.

Surface Cleaning Guidelines

Instructions for cleaning decks and house siding.

Additional Cleaning Tips

Hard Surface Cleaning

Methods for cleaning patios, brick, and stone.

Vehicle and Outdoor Item Cleaning

Tips for cleaning cars, boats, furniture, and equipment.

Optional Cleaning Accessories

Pump Protection and Extension

Accessories for pump guard and extending hose reach.

Specialized Cleaning Attachments

Accessories like rotating brushes and pipe cleaning kits.

Advanced Accessories

Sandblasting and Foaming Attachments

Accessories for rust removal and detergent foaming.

Wide Area Surface Cleaner

Accessory for efficient cleaning of large flat areas.

Troubleshooting

Startup and Pressure Issues

Common causes and solutions for motor not starting or low pressure.

Inconsistent Pressure Output

Troubleshooting advice for fluctuating pressure.

Further Troubleshooting

Detergent and Leak Issues

Solutions for no detergent, leaks, or noisy pump operation.

Water Leaks and Oil Drip

Troubleshooting leaks from the pump and oil drips.

Kärcher K 3.48 M Specifications

General IconGeneral
Max Pressure120 bar
Flow Rate360 l/h
Hose Length6 m
Cable Length5 m
Max. Water Inlet Temperature40 °C
Detergent TankYes
Power1600 W
