Illustrations on Page 2
1 Coupling element for water connection
2 Quick coupling for high pressure hose
3 Storage for spray lance
4 Water connection with integrated sieve
5 Appliance switch "0/OFF“/ „I/ON“
6 Storage for spray lance
7 Transport handle
8 Storage for accessories
9 Suction hose for detergent
10 Mains cable with mains plug
11 Wheels
12 Trigger gun
13 Lock trigger gun
14 Key to detach the high pressure hose
from the trigger gun
15 High pressure hose
16 Spray lance with pressure regulation
(Vario Power)
17 Spray lance with Dirtblaster
18 Rotary wash brush
Special accessories expand the possibilities
of using your appliance. Please contact your
KÄRCHER dealer for further information.
Mount loose parts delivered with appliance
prior to start-up.
Illustrations on Page 3
Illustration
Push the wheels into the intake and se-
cure with the enclosed plugs, watch for
positioning of plug.
Illustration
Place the transport handle into the in-
take until you feel resistance. Use the
heel of your hand or a soft rubber mallet
to position it.
Illustration
Hook the accessories net into the hooks
shown in the illustration.
Illustration
Place the bottom holder into the recesses
and push forward until it audibly locks in.
Insert the top holder and push down all
the way.
Illustration
Push the high pressure hose into the
trigger gun until it locks audibly.
Note: Make sure the connection nipple
is aligned correctly.
Check the secure connection by pulling
on the high pressure hose.
몇 Warning
According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.
Caution
Always connect the system separator to
the water supply, never directly to the appli-
ance!
Note: Impurities in the water can damage
the high-pressure pump and accessories.
For protection, the use of the KÄRCHER
water filter (optional accessory, order no.
4.730-059) is recommended.
Observe regulations of water supplier.
For connection values, see type plate/tech-
nical data.
Use a fibre-reinforced water hose (not
included) with a standard coupling.
(Minimum diameter 1/2 inch (13 mm),
minimum length 7.5 m).
Illustration
Screw the coupling element to the wa-
ter connection on the appliance.
Push the water supply hose onto the
coupling unit, then connect it to the wa-
ter supply.
Operation
Description of the Appliance
Special accessories
Before Startup
Install wheels
Install the transport handle
Attach the accessories net
Install the storage for trigger gun
Connect the high pressure hose to the
trigger gun
Water supply
Water supply from mains
