English 7
STEP 8:
Insert one end of the high pressure
hose into the trigger gun until it locks
audibly.
Note: Make sure the connection nip-
ple is aligned correctly. Check the
connection by pulling on the high
pressure hose.
Check the secure connection by pull-
ing on the high pressure hose.
Disconnect:
Press the disconnect key on the trig-
ger gun and remove the high pres-
sure hose from the trigger gun.
STEP 1:
Connect the high pressure hose to
the unit’s high pressure outlet.
STEP 2:
Insert the spray wand of your choice
into the trigger gun. Press in against
the spring tension and twist into
locked position.
STEP 3:
Install the supplied connector to the
unit’s water inlet.
STEP 4:
Screw the supplied garden hose con-
nector on to the end of your garden
hose.
Connect the high pressure hose to
the trigger gun
OPERATING INSTRUCTIONS
