14 English
Technical specifications
Electrical connection
Voltage 240
1~50
V
Hz
Connected load 2,1 kW
Protection class IP X5
Protective class I
Mains fuse (slow-blow) 13 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 10 l/min
Max. Suction height 0,5 m
Performance data
Working pressure 12 MPa
Max. permissible pressure 14,5 MPa
2100 psi
Water flow rate 6,8 l/min
Max. flow rate 8,0 l/min
Detergent flow rate 0,3 l/min
Recoil force of the trigger gun 17 N
Dimensions and weights
Length 411 mm
Width 305 mm
Height 584 mm
Weight, ready to operate with
accessories
14,7 kg
Subject to technical changes.
