Operating instructions KM 100/100 R D English
28
Stop machine
! Raise the side broom
! Raise the sweep roller
! Turn ignition key to "0" and
remove it
Note:
The dust filter is automatically
dedusted for approx. 15 s after
shutting down of the machine.
Do not open the unit cover while this
is going on.
! Open unit cover, engage stay bar
Close fuel shut-off valve
! Slide lever towards "S"
Note:
The machine is provided with an
automatic parking brake, which is
activated when the engine is
stopped and the driver leaves his
seat.
Empty the swept material
container
! Wait until automatic filter
dedusting is completed and the
dust has settled before opening
the debris container and
emptying it.
! Pull out debris container
! Empty the swept material
container
! Slide in and lock the debris
container
! Then perform the same
operations on the opposite debris
container
Usage instructions
Safety instructions when
sweeping
Warning!
— Never sweep up packing straps,
wires or the like as this could
damage the sweeping
mechanism.
— When the coarse-dirt flap is
open, the main brush can hurl
stones or stone chips forwards.
Make sure that nobody, no
animals or objects are
endangered.
Notes:
! For optimum cleaning effect,
match the driving speed to suit
the actual conditions.
! During operation the debris
container should be emptied at
regular intervals.
! Lower the sweeping roller for
surface sweeping.
! Lower the side broom for
cleaning side edges.
Sweeping dry ground
! Close the bypass cover on left
behind the seat
Sweeping damp or wet
ground
! Open the bypass cover on left
behind the seat
— This protects the filter from damp
