Kärcher OC 3 User Manual

– 7
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
Australia
KÄRCHER Pty. Ltd.
40 Koornang Road
Scoresby, Victoria 3179
1800 675 714 (Free Call)
www.karcher.com.au
New Zealand
Karcher Ltd.
66 Allens Road,
East Tamaki, Aukland
(09) 274-4603
www.karcher.co.nz
Technical specifications
Electrical connection
Nominal battery voltage 6 V
Rated power of appliance 45 W
Protection class IP X4
Protective class
Charging time for empty battery 3 h
Rated charger voltage 100-240
1~50-60
V
Hz
Output voltage, charger 9,5 V
Output current, charger 600 mA
Operating time with full charge 15 min
Max. Suction height 0,5 m
Performance data
Working pressure 0,5 MPa
Volume, fresh water reservoir 4 l
Max. ambient temperature 45 °C
Ambient temperature (min.) 0 °C
Dimensions and weights
Length 235 mm
Width 277 mm
Height 202 mm
Weight, ready to operate with ac-
cessories
6,2 kg
Values determined as per EN 60335-2-79
Sound pressure level L
pA
Uncertainty K
pA
69
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncertain-
ty K
WA
84 dB(A)
Subject to technical changes.
Accessories and Spare Parts
Customer Service
9EN

Kärcher OC 3 Specifications

General

Form factor	Compact
Hose length	2.8 m
Power source	Battery
Water filter	Yes
Cleaning type	Dry
Product color	Black, Yellow
Tank capacity	4 L
Detergent tank	-
Pressure range	Low-pressure
Protection class	III
International Protection (IP) code	IPX4
Battery life	15 min
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Battery recharge time	3 h
Uncertainty K	3 dB
Maximum flow rate	120 l/h
Sound power level	84 dB
Sound pressure level	69 dB
Working pressure (max)	- bar
Maximum water temperature	40 °C
Wash brush	No
Package weight	2900 g

Weight and Dimensions

Depth	277 mm
Width	234 mm
Height	201 mm
Weight	2200 g
