Kärcher PST 222 - Care and Maintenance; Cleaning the Brushes and Felt Discs; Technical Specifications; Circuit Diagram

7
English
n Technical Specifications
Electricity supply 240 Volt 1~50/60 Hz
Class of protection II
MAX power 350 Watt
Motor speed 7500 r/min
Pad rotation speed 700 r/min
Filter volume 4 L
Cable length 5 m
Weight 8,3 kg
Mean sound level (DIN 45 635) 63 dB(A)
Dimensions: (length x width x height) 350 x 350 x 1000 mm
Mains cable: Order no. GB 6.647-914
AUS 6.641-973
n Circuit Diagram
M: Motor
I: Switch
C: Capacitor
L1/L2: Interference suppression coils
H: Lamp
VACUUM AND POLISHING MACHINE PST 222
n Care and maintenance
Always pull out the mains plug before carrying out any maintenance work.
Use only original spare parts.
Cleaning the brushes and felt discs
The brushes can be cleaned very simply with soap and water.
Clean the felt discs with soapsuds and a brush. Then rub the felt discs down with a
damp cloth and leave them to dry on a flat surface.
Worn out brushes or polishing pads can be re-ordered under the following numbers:
Brush pads, hard (qty 3, white) Order no. 6.959-031
Brush pads, soft (qty 3, black) Order no. 6.959-032
Polishing pads (qty 3) Order no. 6.959-033
