General notes
Read these original instructions and the
enclosed safety instructions before us-
ing the device for the first time. Act in ac-
cordance with them.
Keep both books for future reference or for future own-
ers.
● If the operating instructions and safety instructions
are not observed, the device can be damaged and
dangers could arise for users and other persons.
● Notify the dealer immediately in the case of shipping
damage.
● Check the package contents when unpacking for
missing accessories or for damage.
Environmental protection
The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic appliances contain valu-
able, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can
pose a potential threat to human health and the environ-
ment. However, these components are required for the
correct operation of the appliance. Appliances marked
by this symbol are not allowed to be disposed of togeth-
er with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.com/REACH
Intended use
● This spray retraction device is intended for wet
cleaning of carpets.
● This device is suitable for commercial use, e.g. in
hotels, schools, hospitals, factories, shops, offices,
and rental companies.
Overview of the device
Quick Start Guide
Illustration A
1 Connect the spray / suction hose to the device, con-
nect the spray / suction hose to the angle piece
2 Mix cleaning solution, fill fresh water tank
3 Selecting operating modes
4 Cleaning
5 Emptying the fresh water tank
6 Empty the wastewater container
7 Fill the fresh water tank(without detergent), rinse
the device
8 Clean the fluff filter, clean the fresh water filter
9 Allow the device to dry
Description of the device
Illustration B
1 Manual nozzle for upholstery cleaning (Puzzi 10/1
only)
2 Cable hooks
3 Adapter for accessories (Homebase)
4 Holder for accessories
5 Mains cable
6 Quick Start Guide
7 Fresh water tank
8 Fresh water filter
9 Spray switch
10 Suction switch
11 Casing
12 Type plate
13 Steering roller
14 Spray hose connection
15 Socket for additional brush wash head PW 30/1
(Puzzi 10/2 Adv only)
16 Suction hose connection
17 Defoaming agent container (Puzzi 10/2 Adv only)
18 Cover
19 Storage compartment for detergent tabs (Puzzi 10/
2 Adv only)
20 Device carrying handle including suction pipe hold-
er
21 Floor nozzle for carpet cleaning
22 Carpet adapter
23 Floor nozzle latch
24 Suction pipe
25 Nozzle mouthpiece
26 Union nut
27 Handle
28 Angle piece
29 Lever on the manifold
30 Spray hose
31 Suction hose
General notes...................................................... 10
Environmental protection..................................... 10
Intended use........................................................ 10
Overview of the device ........................................ 10
Start-up................................................................ 11
Operation............................................................. 11
Cleaning methods ............................................... 12
Transport ............................................................. 12
Storage................................................................ 12
Care and service ................................................. 12
Troubleshooting guide......................................... 13
Warranty.............................................................. 13
Accessories and spare parts ............................... 13
Declaration of Conformity.................................... 13
Technical data ..................................................... 14
