Technical specifications
Puzzi 30/4
Mains voltage V 120
Frequency Hz 1~ 60
Type of protection -- IPX4
Protective class -- I
Rated current A 9.5
Air volume (max.) CFM (l/s) 150 (71)
Negative pressure (max.) mm (kPa) 2470 (24.2)
Rated current, spray pump A 0.8
Spray pressure (max.) psi (MPa) 87 (0.6)
Spray volume gal/min (l/min) 0.8 (3.0)
Temperature of the cleaning solution (max.) °F (°C) 122 (+50)
Container capacity gal (l) 7.9 (30)
Length x width x height in (mm) 23.0 x 18.0 x 36.5
(580 x 460 x 930)
Working width of the floor nozzle in (mm) 13.8 (350)
Typical operating weight lbs (kg) 57.3 (26)
Ambient temperature °F (°C) 32...104 (0...+40)
Values determined to EN 60335-2-68
Sound pressure level L
pA
dB(A) 68
Uncertainty K
pA
dB(A) 2
Power cord SJTW 3/14 AWG
Part no.: Cable length
CUL 6.648-178.0 50 ft (15 m)
