Kärcher Puzzi 8/1 C Quick Start

QUICKSTART
5.964-158.0 02/12
4
A B A Use the lever on the bender to spray on
detergent solution.
B Spray and suction off detergent solution
in one work cycle.
5
A B A Highly soiled spots should be presoaked
and the detergent solution should soak
5 to 10 minutes.
B Vacuum up the detergent solution in the
course of the second work step.
Finish operation
1
A B C A Switch off the vacuuming and spraying
switches.
B Remove the lid.
C Empty the wastewater reservoir.
2
A B C A Fill the fresh water tank with clear water
and to rinse/clean the appliance.
B Spray the accessories into the wastewater
tank, along with fresh water
(approx. 1-2 minutes)
C Empty the fresh water reservoir and
switch the appliance off.
D Empty the wastewater reservoir.
3
A B C A Shortly activate the lever on bender to
decrease the pressure. Pull the coupling
backwards.
B Place the lid loosely to let the appliance dry
out.
Operation
2 EN

Kärcher Puzzi 8/1 C Specifications

General

Type	Drum vacuum
Cleaning type	Wet
Dust capacity	- L
Product color	Black, Grey, Yellow
Dust container type	Bagless
Cord length	7.5 m
Carrying handle(s)	Yes
Maximum area covered	18 m²
Clean water tank capacity	8 L
Dirty water tank capacity	7 L
Airflow	61 l/s
Proper use	Professional
Noise level	- dB
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	Water
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Maximum input power	1200 W
Annual energy consumption	- kWh

Weight and Dimensions

Depth	530 mm
Width	330 mm
Height	440 mm
Weight	9800 g
