Kärcher SC 5 - Quick Reference; Operation; Attaching the Accessories; Removing the Accessories

– 6
 Illustrations on Page 2
Illustration
 Fill the water reservoir up to the "MAX" marking.
Illustration
 Insert the steam plug into the appliance connector.
Illustration
 Plug in the mains plug.
 Switch on the appliance by turning the selector
switch.
Illustration
 Display - steam gun lights up green.
Display - steam level lights up white and/or Vapo-
Hydro level lights up red.
Display - heater blinks green.
Once the display (heater) lights up permanently,
the steam cleaner is ready to use.
Illustration
 Connect the accessories to the steam gun.
 Operate steam lever.
 Illustrations on fold-out page!
 Illustration
Open the cover of the appliance socket.
 Tightly insert the steam plug into the appliance con-
nector. The plug must click into place audibly.
To disconnect:
Press the cover of the appliance connector down
and disconnect the steam plug from the appliance
connector.
 Illustration -
Connect the required accessories (see Chapter
"How to use the accessories“) to the steam gun. In-
sert the open end of the accessory on the steam
gun and push onto the steam gun until the unlock-
ing button of the steam gun locks into place.
 Illustration
Use the extension tubes if necessary. To do so,
connect one or both extension tubes to the steam
gun. Insert the required accessories on the free
end of the extension tube.
 Move the child protection unit toward the back
(steam lever locked).
 Illustration
To detach the accessory parts, press the unlocking
button and pull the items apart.
A6 Locking door for accessories compartment
A7 Maintenance lock
A8 Carrying handle
A9 Holder for accessories
A10 Accessories storage
A11 Storage for mains connection cable
A12 Storage holder for floor nozzle
A13 Mains cable with mains plug
A14 Running wheels (2 ea.)
A15 Steering roller
B1 Steam gun
B2 Steam lever
B3 Unlocking button
B4 Child lock
B5 Steam hose
B6 Steam plug
C1 Detail nozzle
C2 Round brush Black
C3 Round brush Red
C4 Power nozzle red
C5 Round brush Large
D1 Hand nozzle
D2 Microfibre cloth cov-
er
E1 Extension tubes (two tubes)
E2 Unlocking button
F1 Floor nozzle
F2 Side-flaps
F3 Microfibre floor cloth 2 pieces
G1 Decalcifying sticks
Option
H1 Steam pressure iron
H2 Upper steam button
H3 Display - heater (ORANGE)
H4 Lower steam button
H5 Steam lock
H6 Temperature controller
H7 Steam plug
Quick Reference
Operation
Attaching the Accessories
Removing the Accessories
13EN
