Power Head-XP12
ITEM PART NO. REF NO. DESCRIPTION NOTES
100 86434050 52123WI
POWER HEAD COVER SR XP 12, CPL., BASALT
GRAY
101 86434060 52038ER EXHAUST FILTER
102 86434070 52114BG COVER EXHAUST FILTER SR XP, BASALT GRAY
103 86434080 52018UL SWIVEL NECK BEARING RIGHT HAND
104 86145120 5101 SWIVEL NECK SUPPORT RIGHT HAND
105 86434090 52023UL SWIVEL NECK ASSEMBLY
106 86146130 5717 SWIVEL NECK BEARING LEFT HAND
107 86434100 52020UL SWIVEL NECK SUPPORT LEFT HAND
108 86434110 52013 MOTOR SUPPORT GASKET
109 86434120 52194ER VACUUM MOTOR, 1000 W/120V, INCL. CABLE
109a 86139400 05117S CARBON BRUSH VAC MOTOR
110 86434130 52040UL CABLING MOTOR, UL, 3-WIRE
111 86144710 5100 RUBBER MOUNTING
112 86434140 52059UL MOTOR HOUSING, 3-WIRE, UL-VERSION
113 86434150 52011ER BELT TIGHTENER
114 86143620 5462 MOTOR PULLEY
115 86434160 52115ER COVER FOR AIR CHANNEL
116 86434170 52199UL CABLING SWIVEL NECK, 3-WIRE, UL-VERSION
117 86434180 52103 REED-SWITCH SWIVEL NECK
118 86434190 5870ER PCB POWER SUPPLY / CONTROLLER , 100-120V
119 86434200 52009ZG FOOT PEDAL SR XP, CPL., ZINC YELLOW
120 86434210 52052 FELT STRIP
121 86434220 52054 CABLE GUIDE
122 86434230 52234kg
BRUSH ROLLER RELEASE BUTTON SR XP 12/15,
R.H., KARCHER GREY
123 86434240 52112 SUPPORT MOTOR HOUSING
124 86434250 52021 SUPPORT LEVER SR XPN
125 86145460 5107-1 SUPPORT SPRING
126 86434260 52102SW AXLE ASSEMBLY, BLACK
127 86434270 52132SW BEARING BLOCK SR XP 12, RIGHT HAND, BLACK
128 86004950 5010WI BRUSH ROLLER SR XP12
129 86434280 52033ER
RELEASE RING BRUSH ROLLER SR XP 12/15, R.H.
WITH SPRING
130 86434290 52195WI
CHASSIS SR XP 12, UL-VERSION, SPARE CPL.,
BLACK INCL. POS. 120 & 123, W/O BUMPER
131 86143570 5112sw MOTOR PULLEY COVER
132 86138240 5463 BELT 2MR-310-6
134 86434300 52108 SENSOR SR XP 12N
135 86005000 5110 BELT 219 3M-HDTII-6
141 86434310 52111 BEARING BLOCK SR XP 12, L. H., CPL.
142 86145080 5060ER
SERVO MOTOR WITH GEAR BOX *1 WITH
CONNECTING CABLE 135MM
143 86319380 5174sw PILE ADJUSTMENT WHEEL, BLACK
144 86406150 5172ZG
ACCESS DOOR, ZINC YELLOW, (INCL. POS. 145 +
146)
145 86145330 5304 ACCESS DOOR SPRING
146 86138000 5303 ACCESS DOOR AXLE
