– 7
also be washed in the washing ma-
chine at a temperature of up to 60°C
(without the use of fabric softeners).
Let the cleaned appliance dry prior
to assembly.
Charge the battery.
Store the appliance upright in a dry
room.
Refill detergent.
Pump mechanism in spray botte
defective, contact dealer.
Check the charge/operations display:
No signal or slowly blinking signal:
Charge the battery.
With a rapidly blinking signal: In-
form your dealer.
Lightly press the device against the
glass, just slide over.
Hold the device at the correct angle
to the glass. This is achieved, when
the distance between the lower end
devices and the glass is about 10
cm.
Use KÄRCHER cleaning detergent,
because it is specially matched for
the window vac.
Adjust the dosing of detergent.
Spray sufficient liquid on the glass.
Glass must not be too dry.
Clean the squeegee regularly.
Reverse the used pull-off lip. Pull
the squeegee to the side. After-
wards wet the squeegee in the area
of the curve with water or detergent.
Slide the squeegee back in the
holder in reverse order.
Complete worn squeegee, take out
as described above and replaced
by a new lip.
The cleaning should not be done in
direct sunlight or excessive heat.
Empty the waste water tank (max.
100 ml content).
Subject to technical modifications!
Storing the Appliance
Troubleshooting
Spray bottle does not spray
Machine does not start
Streaks while cleaning
Water is leaking from the
side of the tank
Technical specifications
Type of protection IP X4
Volume of waste water
tank
100
0
ml
Operating time with full
charge
35 min
Nominal battery voltage 3,7 V
Rated power of appli-
ance
10 W
Charging current for
empty battery
185
0
min
Output voltage, charger 5,5 V
Output current, charger 600
0
mA
Sound pressure level
(EN 60704-2-1)
50 dB(A)
Weight 0,6 kg
Battery type Li-Ion
