22
Installation
08
SECURE CEILING HOOD FRAME & METAL FILTERS
10
1. Ret the frontal fascia panel with the 4 x M6 x 12mm screws shown and reconnect the
LED light connection.
2. Replace the lters x 2 [10] or replace with optional washable lters WRWFILT18.
10
10 x 2
1
2
WRWFILT18
OPTIONAL WASHABLE FILTERS
AVAILABLE TO PURCHASE SEPARATELY
OR replace with
Optional WRWFILT18
Washable lters
M6 x 12mm (x4)
