Karma KM-2000 Series User Manual

10
4.1.2 Folding
4.1.2.1 Swing up the footplates. (See Figure 4.5)
4.1.2.2 Pull up on the seat upholstery by holding it in the centre of its front and
back edge. (See Figure 4.6)
4.1.2.3 Press the two release levers on the backrest frame (push handle tubes) to
fold the backrest down for compact storage and easy transport. (See Figure
4.7)
4.1.2.4 Folding is now completed. (See Figure 4.8) (Travel bag is optional)
Figure 4.5
Figure 4.6
Figure 4.7
Figure 4.8
CAUTION:
● Be careful not to get your fingers caught when folding the wheelchair.
4.1.3 Rear Wheel
4.1.3.1 Your wheelchair may be supplied with quick-release wheels. If so, please
follow the instructions below.
4.1.4 Rear Wheel Removal
4.1.4.1 Support the weight of the chair with one hand by holding the push handle.
4.1.4.2 Depress the hub cover and hold down the quick-release mechanism.
4.1.4.3 Remove the wheel. (See Figure 4.9)
