Karma KM-2000 Series User Manual

9
4. OPERATION
4.1 Preparing For Use
4.1.1 Unfolding
4.1.1.1 Holding the armrests, pull outwards. (See Figure 4.1)
4.1.1.2 Pointing your fingers inward with the palm of your hand on the frame, push
down until the seat is fully lowered. Make sure the frame is firmly seated
in its holder. (See Figure 4.2)
4.1.1.3 Flip the footplates down. (See Figure 4.3)
4.1.1.4 Ready for action! (See Figure 4.4)
Alternatively, you can stand at the side of the wheelchair and complete step 1 by
pulling the nearest armrest towards yourself and pushing the other one away.
Figure 4.1
Figure 4.2
Figure 4.3
Figure 4.4
While completing step 2, never put your fingers around
the sides or under the wheelchair as they can be trapped
between the seat and the frame. (See the right figure.)
