5
NUMER OF ASSEMBLY
NUMBER OF SUB-ASSEMBLY
NUMBER OF PART
NAME OF ASSEMBLY
NAME OF SUB-ASSEMBLY
NAME OF PART
002-01
PUMP MOTOR
002-03
COMPLETE PUMP
003-01
WHEEL DRIVE MOTOR
003-08
DRIVING SHAFT
003-09
SUPPORTING SHAFT
004
SET OF STABILISING ROLLERS
005
WASHING UNIT
006-08
ELECTROMAGNETIC VALVE
006-09
COMPRESSED AIR SUPPLY SYSTEM
007
PNEUMATIC WHEEL STABILISATION UNIT
008-01
HEATER
008-02
THERMOSTAT
009-01
ELECTRIC BOX
010-01
SOUND ABSORBING PERFORATED PVC SHIELD
010-02
GRANULATE BASKET
010-05
OUTLET PIPE
010-06
OUTLET PIPE CLAMPING RING
010-08
PLASTIC UPPER PROTECTIVE COVER
010-09
WASHING CHAMBER FLAP SPRING
TECHNICAL DATA
Wheel diameter range
560 - 800 mm
Wheel width range
135 - 360 mm
Maximum weight of wheel
60 kg
Washing times, factory set (adjustable, 3 programmes)
20, 40, 60 sec
Drying time, factory set (adjustable, 1 programme)
15 sec
Water heating time to 50ºC
60 - 120 min
Heater power
4 kW
Pump drive 3-phase 400 V, 50 Hz, 5.5 kW
2900 rpm
Pump efficiency
600 lpm
Wheel drive 3-phase 400 V, 50 Hz, 0.37 kW
930 rpm
Motors and drive power
6 kW
Water pressure
4 bar
Quantity of water
300 l
Quantity of WULKAN MIX granulate
20 kg
Quantity of WULKAN TURBO washing concentrate
3 l
Compressed air working pressure
8 - 12 bar
Acoustic power level
89.5 dB
Dimensions (width x depth x height)
960 x 1210 x 1450 mm
Net weight
330 kg
Maximum limiting number of washing process starts (service lock)
500 starts
