Kasda KW58283 - Rear and Side Panel Ports

Wireless ADSL Router USER MANUAL
6
Rear panel
Side Panel
USB:connect the device to printer
Port
Function
DSL
Connect the device to an ADSL telephone jack or splitter
using a RJ-11 telephone cable
ETH1-4
Connect the device to user’s PC's Ethernet port, or to the
uplink port on user’s hub/switch, using a RJ-45 cable
WIFI
Switch the wireless function on or off
RESET
System reset or reset to factory defaults
WPS
A convenient way for WPS set.
ON/OFF
Switch it on or off
POWER
Connect to the supplied power adapter
